Cablenet 8 Port 10/100/1000 Plastic Desk Switch

PLANET GSD-804 Green Networking Switch is an ideal solution in line with the energy-saving trend worldwide. The GSD-804 is an 8-port Gigabit Ethernet Switch, bringing both benefits of energy saving and Gigabit wire speed performance. It is specially designed for home networking, SOHOs and enterprises.

Energy Savings - The GSD-804, incorporating two advanced Green Networking technologies, is able to provide power saving by up to 40% but maintains high performance efficiently.

(1) Hibernation Link Down power saving goes beyond IEEE specifications to automatically lower power for a given port when it is not linked. With the Hibernation Link Down power saving technology, the GSD-804 will automatically adjust power usage of the ports that are shut down or not connected to network device.

(2) Intelligent use of power uses an intelligent algorithm that actively determines the appropriate power level based on cable length. When the GSD-804 is connected with Ethernet cable shorter than 20m, a device can obtain maximum power savings because the GSD-804 would automatically detect the Ethernet cable length and diminish power usage. The connected device can substantially reduce the overall power consumption, which makes a significant contribution to energy savings.

8 x 10/100/1000Mbps Gigabit Ethernet ports
Complies with IEEE 802.3, 10BASE-T, IEEE 802.3u 100BASE-TX, IEEE 802.3ab 1000BASE-T
Supports auto MDI/MDI-X function
Hardware-based 10/100Mbps, half/full duplex and 1000Mbps full duplex mode, flow control and auto-negotiation
Features Store-and-Forward mode with wire-speed filtering and forwarding rates
IEEE 802.3x flow control for full duplex operation and back pressure for half duplex operation
Integrated address look-up engine, supporting 4K absolute MAC addresses
9K Jumbo packet size
Power saving ability for Green networking
Automatic address learning and address aging
Supports CSMA/CD protocol
Made from plastic, desktop size and wall-mount design
LED indicators for system power, per port Link/Act
5V DC, 1A external power adapter
FCC, CE Class B compliant

SEE TECHNICAL DATA SHEET FOR FULL DETAILS
